| Items | Parameter |
|---|---|
| Syringes | 5, 10, 20, 30, 50 mL of calibrated syringes |
| Flow rate |
0.1~1500 mL/h (specified value 0.1~999.9 mL/h, 0.1 mL/h step)
(specified value 1000 mL/h or above, 1mL/h step) 0.1~900 mL/h (0.1 mL/h step) 0.1~600 mL/h (0.1 mL/h step) 0.1~400 mL/h (0.1 mL/h step) 0.1~150 mL/h (0.1 mL/h step)
50 mL syringe
30 mL syringe 20 mL syringe 10 mL syringe 5 mL syringe |
| Purge rate |
5~1500 mL/h
5~900 mL/h 5~600 mL/h 5~400 mL/h 5~150 mL/h
50 mL syringe
30 mL syringe 20 mL syringe 10 mL syringe 5 mL syringe |
| KVO flow rate |
0.1~1 mL/h 0.1~5 mL/h |
| Infusion Mode | Speed mode, Body Weight mode, Time mode, Drug Library mode |
|
Accuracy of flow rate (Nominal value) |
Accuracy including syringe: within ±2% Mechanical accuracy: within ±1% |
| Display range of volume delivered | 0.1~9999 mL (0.1~999.9 mL, 0.1 mL step) (1000~9999 mL, 1 mL step) |
| Setting of delivery limit | 0.1~9999 mL (0.1~999.9 mL, 0.1 mL step) (1000~9999 mL, 1 mL step) |
| Occlusion detection pressure |
"H": 800±200 mmHg (106.7±26.7 kPa) or 1.09±0.27 kgf/cm² "C": 500±100 mmHg (66.7±13.3 kPa) or 0.68±0.13 kgf/cm² "L": 300±100 mmHg (40.7±13.3 kPa) or 0.41±0.13 kgf/cm² |
| Alarms |
'Occlusion', 'Nearly empty', 'Finish', 'Syringe dislocated', 'Plunger/Clutch disengaged', 'Battery low', 'Battery exhausted', 'Power cable disconnected', 'Flow rate over limit', 'Volume over limit', 'System error', 'Non-operation time over' |
| Power |
AC110~230V ±10%, 50/60 Hz ±1 Hz Inner NiMH battery: DC12 V Continuous operation time of battery: over 6 hours for one channel when battery is recharged for 12 hours, at flow rate of 5 mL/h. |
| Operation conditions |
Ambient temperature: 5°C ~ 40°C, Relative humidity: 20% to 80% |
| Storage conditions |
Ambient temperature: -20°C ~ 55°C, Relative humidity: ≤95% |
| Power consumption | Approximately 10 W |
| Dimension | 306mm (Width) × 135mm (Height) × 127mm (Depth) |
| Weight | 2.25kg (with clamp base) |
| Adjustable alarm sound | Adjustable button sound | Operation error prompt |
| Calibrating syringe automatically | Easy installation of syringe | Fast rate control |
| Identifying syringe size automatically | 2 CPU control | "Purge" button activate safe protection |
| 3-level occlusion alarm limits setting | Vehicle power supply interface | Flow rate setting button lock |
| Limits setting | Drug library | Abundant optic and sound alarm |
| Delivered volume inquiry | Self-testing when start up | AC and internal power indication |
| 1000 history records | LCD screen | Standard RS232 interface |
| Stand by mode | Nearly empty setting (3 modes) | Clear date when power on |
| Automatically reducing impact dose release after occlusion | Automatically switch to battery when circuit failure | Multi-direction clamp for either horizontal or vertical fixation |
| Automatic charging when connect to the circuit | Dynamic pressure monitoring | Manual and programmable bolus |
